    Automatic Overflow Liquid Filling Machine

    Automatic Overflow Liquid Filling Machine
    Automatic Overflow Liquid Filling Machine
    Product Code : AOLF - 96
    Product Description

    Automatic overflow liquid filling machine


    In pressure overflow filling systems the product is pumped or gravity fed from a tank through a filling valve to the container. The filling valve contains an over flow tube to drain the excess product back to the supply tank and prevent overfill. The fill level of the container is determined by the depth of the overflow port within the neck of the container. When the product reaches the overflow port, the fill is completed, but the flow continues through the overflow tube until the seal on the container is broken and the valve sleeve covers the ports in the filling nozzle and stops the flow. The fill level will be the same regardless of bottle inconsistencies.

    Technical Specifications:-

    Model Azesto - 01
    No. of filling head** As per required
    Fill Size 200 ML to 5 Ltrs
    Viscosity Range 2000 CPS ( Centipoises)
    Foamy Product*** Yes
    Corrosive Product**** Yes
    Heated Product***** Yes
    Electrical Specification 415v , Single Phase, 50 Hz
    Air Requirement 80 to 100 PSI @ 2 CFM
    Overall Dimension (Approx.) 1981.2 mm (H) X 1422.4 mm(D) X 3048mm(L)
    Weight (Approx.) 1100lbs. (498.95 Kg.)

    Key Feature:-

    No Bottle No Filling System
    Pneumatic Diving nozzle
    Pneumatic Bottle Stoppering Arrangement
    Pneumatic operated valve
    Stainless Steel no drip Fill Heads
    On the fly adjustments
    Stainless Steel drip collection tray
    Stainless Steel Food Grade Manifold with Tri-clover connections
    304/316 Stainless Steel Food Grade Over flow Tank and float tank
    HDPE reinforced tubing
    10 Feet Stainless Steel variable speed Conveyor
    Suitable Transfer Pump

    Salient Features:-

    PLC Based Controller
    316 Stainless Steel Upgrade
    Overall production counter.
