    Capsule Filling Machines

    Capsule Filling Machines
    Capsule Filling Machines
    Product Code : CFM 18
    Brand Name : AZESTO
    Price And Quantity
    • Minimum Order Quantity
    • 1
    • Unit of Measure
    • Piece/Pieces
    Product Description
    Product Detail:-

    (**ALTERNATE SMALL CAPACITY MODEL 50 Capsules/Cycle) Capsule filling machine with 300 holes for setting capsule manually and then filling powder or any material to be filled in capsule are filled. After filing material in half of capsule the remaining powder is washed away and then the machine is closed, the final out put after this cycle is 300 capsules ready to use.


    Size 300 holes
    Output 300 capsule/cycle**
    Overall 460 X 460 X 560(H) mm2


    CAPSULE LOADER M/C.:-

    Motor 3 phase , 0.25 Hp.
    Size 300 holes**
    (**ALTERNATE SMALL CAPACITY MODEL 50 Capsules/Cycle)


    CAPSULE POLISHING M/c.:-

    SALIENT FEATURES:-

    Machine Fabricated From S.S Sheets With G.M.P Requirements.
    High output of polished, shiny and clean Capsules can be achieved.
    Infinitely variable vibrator Speed to control capsules flow

    Technical Specifications:-

    Out Put

    20,000 To 25,000 Cap. Per Hour.

    Drive Motor Polishing Section

    ½H.P

    Polishing Chambers

    One

    Space Required

    5’X3’X6’

    Power Required

    440 Volts, 3 Phase


    Specifications of the Capsule Filling Machines

    Output

    5000 to 6000 capsules per hour. (Can be more with the help of Automatic Loading Machine)

    Capsule Combinations

    Size 00/0, Size 0/1/2, Size 3/4 and Size 5.

    Machine Dimensions

    395 X 240 X 500 MM

    Machine Weight

    45 KG

    Shipping Weight

    70 KG


    Specifications of the Capsule Loading Machines

    Output

    27000 Capsules per hour.

    Loading Speed

    One 300 Holes Tray in 28 Seconds

    Motor

    0.25 HP (0.19KW) - 1440 RPM

    Electrical Supply

    110V Single Phase / 220V 3 Phase / 60 HZ

    220V Single Phase / 415V 3 Phase / 50 HZ

    Dimensions

    L-640MM X W-450MM X H 965MM

    Net Weight

    105 KGS Approx

    Gross Weight

    175 KGS Approx


    We manufacture all kind of Capsule Filling Machine. We provide filling system and also Capsule Filling Machine to suit your pharmaceutical filling process requirement. We also manufacture Capsule Filling Machine as per your filling process and provide Capsule Filling Machine solution as per your requirements. We are leading pharmaceutical machinery manufacturers, exporters from ahmedabad, gujarat, india


    Capsule Loader:-




    Product Detail:-

    Empty Capsule Loader is used in small/medium scale pharmaceutical companies, combination with Hand operated capsule filling machine. It is simple to operate, is time and labour saving. It’s gives higher production at a lower cost and much better standard of accuracy. Capsules are loaded in loading tray in cap up – body down position automatically. (Instead of filling loading tray manually in filling machine)


    Technical Specification:-

    Output 80-90 trays / hour. approx
    Length 630 mm
    Width 430 mm
    Height 780 mm
    Weight 75.0 Kgs.
    Electricals 0.25 hp, 3 ph OR 1 ph
    Trade Information
    • Payment Terms
    • Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T)
    • Supply Ability
    • As per requirement Per Month
    • Delivery Time
    • 4 Week
    • Main Export Market(s)
    • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
    • Main Domestic Market
    • All India
