    Heavy Duty Slugging Tablet Press

    Heavy Duty Slugging Tablet Press
    Heavy Duty Slugging Tablet Press
    Product Code : HDS - 97
    Product Description

    Heavy Duty Slugging Tablet Press

    Product Detail:-

    12stn Bolus Machine


    Operation:-

    12 Stn. ( Max. Output - 15,840 Tablet / Hour)

    Salient Features:-


    In Compliance with cGMP Standard
    Useful for Veterinary Tablets for Animals with Special Toolings
    Heavy duty machine construction
    Machine is Having C.I. Body and C.I. Middle plate
    Paint free tablet manufacturing zone.
    Turret of Special Grade S.G. Iron casting
    Upper punch penetration
    Electronic Digital Tablet cum RPM Counter
    Inter lock Switches to all Guards.
    Double Sided lifting cams
    Lower Guard of polished Stainless Steel & Upper Guards of Acrylic Material
    Aluminum Turret Guards
    Imported needle roller bearing provided at the bottom of turret.
    Effective Dust Extraction Nozzles
    One shot Lubrication System.
    Anti vibration Mounts
    Reverse direction motion protection is provided to avoid accident


    OPTIONAL FEATURES:-


    Available with AC variable Drive & Electromagnetic Clutch (Optional)
    3 Pcs Turret With Electroless Nickel Plating (ENPL) & S.S. 316 Die Plate.
    Auto Lubrication
    Lower Punch Lubrication Spray System for Affervesent & Hygroscopic Powder.

     Technical Specification:-

    MODEL
    Azesto - -D4-12 Slugging
    No. of Station
    12 Station
    Type of Tooling
    Slugging Type
    Output-Tablet/Hr (Min./Max)*
    8,640 to 15,840
    Operating Pressure (Main)
    12 Tons (Max.)
    Depth of Fill
    30 mm
    Max. Tablet Dia.
    40 mm
    Upper Punch Entry
    1.5 to 8 mm
    Turret RPM (Min / Max)
    12 & 22 RPM (Fix Pulley)
    Main Electric Motor
    5 Hp / 930 RPM,440 V, 3 Phase,
    Overall Dimension (mm)
    200 (L) x 910 (W) x 2150 (H)
    Net Weight (Approx.)
    1,100 kgs.
    Gross Weight (Approx.)
    1,500 kgs.

    *Depending upon the characteristic of material and shape & size of tablets.
