Multi Mill

Multi Mill
Multi Mill
Product Code : MM - 38
Brand Name : AZESTO
Trade Information
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
  • Payment Terms
  • Cash Against Delivery (CAD), Cash in Advance (CID), Telegraphic Transfer (T/T)
  • Supply Ability
  • As per requirement Per Month
  • Delivery Time
  • 4 Week
  • Main Export Market(s)
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • Main Domestic Market
  • All India
Product Description
Application & Process:-

Multi Mill is used for wet and dry granulation, pulverization, milling, shredding, chopping, size reduction in Pharmaceuticals, Chemicals, Cosmetics, Ceramics, Colors, Dyestuff, Food products etc. It also finds application in Pesticides, Fertilizers, Spices, Detergents, Insecticides, Plastics and Resins industries.

In multi mill particle size reduction is done through impact in air, on material by blades moving at high speeds, inside a cylindrical sieve. The particles of the desired size pass out through the screen placed inside the hopper.
Operation:-

SS beaters having knife and impact edges rotate within a selected screen
The material fed in the hopper enters into the processing chamber where it moves to the pentery and passes through screen
Output & quality of final products depend on (I) shapes of beaters (Knife/ impact edge) (ii) speed (iii) size of screen


Salient Features:-

Design is cGMP - Current Good Manufacturing Practices compliance
All Product contact parts AISI 316 & non contact parts AISI 304
High speed milling, granulating, pulverizing, mixing and size reduction of wet & dry material.
Output capacity 50 Kg to 200 Kg per hour..
Easy removable contact parts for cleaning & inspection.
Easy Mobility.
Variable force by swing better having knife & impact edges are rotating within screen.
Direction of beaters can be changed by forward- reversible switch.
Various combinations of perforated sieves & wire mesh.

Optional Features :-

AC frequency drive for variable speed.
Belt less Drive
Inline milling process with HSMG and Sifter
Flame Proof electrical.

Safety Features:-

Over load protection.

Technical Specification of Multi Mill Machine:-

Machine Type

Azesto - MM - 200

Out put

50 Kgs To 200 Kgs/hour

Rotor assembly dia

250 mm (approx)

Rotor speed

750 / 1500 / 2300 / 3000 r.p.m.

Beaters

12 knife & impact edges & 2 scrapper blades

Screen dimensions

Iinner diameter-260 mm, ht-135 mm

Motor

TEFC, 3 h.p., 1440 .p.m., 440 v.,
50 cs, 3 hp, a.c. supply

Starter

"Dol" with reversible switch

Material charging height

1445 mm (Approx)

Overall Dimensions (mm)

870 x 965 x 1630 mm Ht.

Net Weight

275 Kgs. (approx)

Gross weight

425 kgs. (approx)

Case dimension (mm)

1200 mm x 1550 mm x 1860 mm (ht)


Note : Specification and features of the machineries are subject to change without any prior notice
