    Oscillating Granulator

    Oscillating Granulator
    Oscillating Granulator
    Product Code : OG - 94
    Product Description

    Oscillating Granulator

    Product Detail:-

    Oscillating Granulator, Granulating Machine is HORIZANTAL TYPE & VERTICAL TYPE granulating system with complete machine manufactured / cladded out of S.S. 304 . The machine will be a gmp model. The machine is complete in all respects and fitted with 1 H.P. T.E.F.C. motor. Standard reduction box and a starter. The body of the machine is “L” shaped fabricated structure and fitted with castor wheels for ease and mobility. Model 8” & 12” are vertical models whereas 15” model is horizontal model. The difference between vertical model and horizontal model is that in vertical model the oscillation is done by a gear mechanism and a vertical shaft is suspended from the top and a propeller type grinder blade moves in oscillating motion and material is pushed through the mesh to get the output of desired mesh size.
    In horizontal model there are diamond shaped blades horizontally fitted and driven by a gear box through gear mechanism to give oscillating motion.


    Technical Specification of Oscillating Granulator, Granulating Machine:-

    Vertical Model:-

    Hopper Capacity

    15 & 30 LTRS. (8” & 12”)

    Screen Area

    8” x 12” respectively

    Output

    30 TO 100 / 200 KGS / HR ( Approximately Depending Upon The Material )

    Power Supply

    1 H.P (8”) 1.5 H.P. (12”). 1440 R.P.M , 440 VOLTS, 3 PHASE, 50 CYCLES A.C.

    Approximate Dimensions

    28” X 16.5” X 48”

    Net Weight

    210 KGS

    Gross Weight

    295 KGS



    Horizontal Model:-

    Hopper Capacity

    34 LTRS

    Screen Area

    12.4” X 14.3” Length

    Output

    30 TO 200 KGS / HR ( Approximately Depending Upon The Material )

    Power Supply

    1.5 H.P 1440 R.P.M , 440 VOLTS, 3 PHASE, 50 CYCLES A.C.

    Approximate Dimensions

    28” X 16.5” X 48”

    Net Weight

    210 KGS

    Gross Weight

    295 KGS


    Circulating Granulator Machine :-


    AS ABOVE ONLY RPM WILL CHANGE UPTO 25 RPM
