    Packing Conveyor

    Packing Conveyor
    Packing Conveyor
    Product Code : PC - 87
    Brand Name : AZESTO
    Product Description

    Packing Conveyor

    Product Detail:-

    Fully Automatic Liquid Line Machine
    Packing Conveyor


    Product Specification:-

    The packing conveyor belt is having stainless steel table top with moving endless sandwich belt in the center. Tabletop is fixed to the same structure made out of SS square pipe and supported on adjustable bolts. Tabletop is of 12 inches working space on both side of the conveyor belt for final visual inspection dn packing.

    Operation:-

    The conveyor belt brings the container or products from the labeling/blister/strip machine, operator in turn pickup these bottles/products and visually inspect the bottles/products and doing necessary action like primary packing, secondary packing, picking and placing at proper place.

    Salient Features:-


    Structure is made of S.S. 304, 30mm sq. pipe, 16 SWG with matt finish


    A/c frequency variable drive.
    belt alignment system for long life and straight running of belt.
    Direct gear drive.
    Length can be made as per customer requirement.
    S.S. elegantly matt finishing.
    Adjustable height of conveyor belt, to align with other machine of the line.
    Self-alignment bearing for easy maintenance.
    Rigid vibration free construction for trouble free performance.

    Optional Features:-


    Castor wheel with lock.
    Extra and table at end of conveyor.
    Special type adjustable angle at initial of conveyor for strip or blister packing
    S.S. chain instead of PVC belt.

    Utility Requirement:-


    Electrical Supply : Single Phase + Neutral + Earthing
    Electrical Load : 0.5 kw.

    Technical Specifications:-


    Model  Azesto-PC
    Direction of Movement Left to Right
    Speed 7.5 Mtr./Min upto 12 Feet Long
    12 Mtr./Min. from 13 Feet to 24 Feet Long
    Power Characteristics 0.25 HP/220 V/50 Hz upto 12 feet long
    0.5 HP/220 V/50 Hz from 13 feet to 24 feet long
    Height of Conveyor 860mm to 910mm
    Belt width 9" or 12" as per requirement
    Belt Details PVC, endless 2 ply sandwich, 2mm thickness
    Machine
    Dimensions
    9" width belt As per requirements (L) x 830mm (W) x 910mm (H)
    12" width belt As per requirements (L) x 900mm (W) x 910mm (H)
    Case
    Dimensions
    9" width belt As per requirements (L) x 1050mm (W) x 1150mm (H)
    12" width belt As per requirements (L) x 1100mm (W) x 1150mm (H)
    Net Weight Depend on Length
    Gross Weight Depend on Length

    We are Manufacturer, Whole Seller, Supplier, Trader, Exporter of Packing Conveyor. We also develop packing conveyor system to suit your packing requirements. We are a leading manufacturer of packing conveyors and other pharmaceutical machinery from Ahmedabad (Gujarat) India.
